🧖 Tylö Sense Sport 2/4 Sauna Heater – 2-4 m³ Capacity
Compact Scandinavian Engineering for Intimate Sauna Spaces – Your Gateway to Authentic Finnish Bathing
♨️ Product Overview
The Tylö Sense Sport 2/4 represents the pinnacle of compact sauna heating technology from Sweden’s legendary TylöHelo brand. Designed as the direct replacement for the acclaimed Tylö Compact 2/4, this versatile electric heater delivers exceptional performance for smaller sauna cabins where space efficiency is paramount.
Featuring innovative Twin Side Chamber Technology and a sophisticated Split Output System, the Sense Sport 2/4 achieves remarkable energy efficiency whilst providing rapid, even heat distribution throughout your sauna room. The sleek black finish and wall-mounted design complement any modern sauna interior, whilst the integrated control panel with mechanical timer and thermostat ensures effortless operation.
Whether you’re creating a home wellness retreat, converting a compact bathroom space, or seeking an efficient heating solution for a petite sauna cabin, the Sense Sport 2/4 delivers authentic Finnish sauna bathing experiences in rooms from 2 to 4 cubic metres.
✨ Key Features
✅ Twin Side Chamber Technology – Dual side chambers with specialised heat directors create optimised air circulation patterns for even heat distribution throughout your sauna
✅ Split Output Power System – Revolutionary dual-power design (2.2 kW / 4.5 kW) reduces energy consumption by up to 30% through intelligent temperature regulation once desired heat is reached
✅ Thermosafe™ Surface Protection – Advanced surface treatment ensures the external casing remains safer to touch during operation, reducing burn risk
✅ Integrated Control Panel – User-friendly built-in controls featuring precise thermostat adjustment, mechanical timer with delay start function, and temperature safety cut-out
✅ Built-in Fragrance Holder – Enhance your sauna experience with essential oils and aromatherapy; simply add water with a few drops of sauna fragrance before heating
✅ High-Quality Tubular Elements – Robust 2 × 2.2 kW heating elements (9600 0902) deliver rapid warm-up and consistent heat output with excellent longevity
✅ Generous Stone Capacity – 7 kg stone capacity provides excellent thermal mass for authentic löyly (steam) when water is cast on the heated stones
✅ Compact Wall-Mounted Design – Space-efficient installation maximises floor area whilst ensuring optimal heat distribution at the ideal height
✅ CE Certified & IPX4 Rated – Fully certified for European safety standards with splash-proof protection rating suitable for sauna environments
✅ Resettable Temperature Cut-Out – Easily accessible front-mounted reset button allows quick restoration after thermal protection activation
⚙️ Technical Specifications
| Specification | Value |
|---|---|
| Power Rating | 2.2 kW / 4.5 kW (switchable) |
| Voltage (2.2 kW) | 200-240V 1N~/2~ |
| Voltage (4.5 kW) | 400-415V 2N~ or 200-240V 1N~/2~ |
| Amperage (2.2 kW) | 10 A |
| Amperage (4.5 kW @ 400V) | 10 A |
| Amperage (4.5 kW @ 230V) | 20 A |
| Cable Size (2.2 kW) | 1.5 mm² |
| Cable Size (4.5 kW @ 400V) | 4 × 1.5 mm² |
| Cable Size (4.5 kW @ 230V) | 3 × 4 mm² |
| Room Capacity (2.2 kW) | 2 – 2.5 m³ |
| Room Capacity (4.5 kW) | 2 – 4 m³ |
| Dimensions (W × H × D) | 348 × 480 × 214 mm |
| Weight | 10 kg |
| Stone Capacity | 7 kg |
| Heat-up Time | 20-30 minutes (typical) |
| Timer Range | 0 – 3 hours with 9-hour pre-select delay |
| Thermostat Range | 60 – 90 °C (adjustable) |
| Mounting | Wall mounted |
| IP Rating | IPX4 |
| Certifications | CE Marked, CB Certified |
| Colour | Black |
| Warranty |
📏 Room Sizing Guide
Basic Formula:
1 kW ≈ 1 – 1.5 m³ sauna room volume
Adjustment Factors:
| Condition | Adjustment |
|---|---|
| Glass door/windows | +1.2 – 2 m³ per m² of glass |
| Uninsulated/log walls | +25 – 50% to volume |
| Stone/tile/glass walls without insulation | +1.2 – 2 m³ per m² |
| Outdoor installation | +25 – 30% to volume |
| High ceiling (above 2.1m) | Additional volume calculation required |
Worked Example:
📍 Example Room: 1.5m × 1.2m × 2.0m
Base volume: 3.6 m³
Glass door (0.7m × 1.9m = 1.33 m²): +2.0 m³
Total calculated: 5.6 m³
This 4.5 kW heater at maximum output: Suitable for 2-4 m³
Result: Consider next size up for rooms with extensive glass
Power Selection Guide:
| Power Setting | Ideal Room Size | Best For |
|---|---|---|
| 2.2 kW | 2 – 2.5 m³ | Very compact saunas, single-person cabins |
| 4.5 kW | 2 – 4 m³ | Small family saunas, bathroom conversions |
⚠️ Important: The minimum room volume must not be exceeded, and the maximum volume must not be exceeded. Undersized heaters struggle to reach temperature; oversized heaters can cause uncomfortable hot spots.
💷 Running Costs
Energy Rate Used: £0.2635/kWh (UK average Direct Debit rate – Ofgem Q4 2025)
Cost Calculation at 4.5 kW (maximum power):
| Usage Level | Sessions/Week | Hours/Year | Annual Cost |
|---|---|---|---|
| 🏠 Light Use | 1 | 75 | £89 |
| 🏠 Regular Use | 2 | 150 | £178 |
| 🧖 Moderate Use | 3 | 225 | £267 |
| 🧖 Heavy Use | 5 | 375 | £445 |
Calculation Formula:
Annual Cost = kW × Hours/Year × £0.2635
Example (4.5 kW heater, Regular Use – 2 sessions weekly):
4.5 kW × 150 hours × £0.2635 = £178/year
Per session cost (1.5-hour session at 4.5 kW):
4.5 kW × 1.5 hours × £0.2635 = £1.78 per session
Cost Savings with Split Output Technology: The Sense Sport 2/4’s intelligent Split Output system can reduce consumption by up to 30% once your sauna reaches the desired temperature, potentially lowering annual costs to approximately £125 for regular use.
| Usage at 2.2 kW Setting | Sessions/Week | Hours/Year | Annual Cost |
|---|---|---|---|
| 🏠 Light Use | 1 | 75 | £43 |
| 🏠 Regular Use | 2 | 150 | £87 |
⚠️ Actual costs depend on usage patterns, session length, room insulation, and current energy rates. Rates verified against Ofgem Price Cap for October-December 2025.
🔌 Installation Requirements
Electrical Requirements:
| Requirement | 2.2 kW Installation | 4.5 kW @ 400V | 4.5 kW @ 230V |
|---|---|---|---|
| Voltage | 200-240V 1N~/2~ | 400-415V 2N~ | 200-240V 1N~/2~ |
| Amperage | 10 A | 10 A | 20 A |
| Circuit Breaker | 10 A | 10 A | 20 A |
| Cable Size | 3 × 1.5 mm² | 4 × 1.5 mm² | 3 × 4 mm² |
| Dedicated Circuit | Required | Required | Required |
| Cable Type | EKK or Fk approved for fixed installation | EKK or Fk approved for fixed installation | EKK or Fk approved for fixed installation |
Minimum Clearances (Normal Mounting):
| Position | Distance |
|---|---|
| Side walls | 20 mm minimum |
| Ceiling | 1250 mm minimum |
| Interior fittings/benches | 30 mm minimum |
| Floor (mounting height) | 170 mm |
| Minimum ceiling height | 1900 mm |
| Maximum ceiling height | 2100 mm |
Minimum Clearances (Recess/Niche Mounting – min. 4 m³ room):
| Position | Distance |
|---|---|
| Side walls | 200 mm minimum |
| Recess depth | 1000 mm maximum |
| Ceiling | 1250 mm minimum |
| Interior fittings | 50 mm minimum |
Ventilation Requirements:
- Fresh air intake: Approximately 125 cm², positioned straight through the wall directly below the heater centreline
- Exhaust vent: Same area as intake, positioned diagonally opposite (high on wall or ceiling)
- Exhaust must vent to same space as door opens into – never directly outdoors
⚠️ IMPORTANT: Installation must be carried out by a qualified electrician
in accordance with BS 7671 (IET Wiring Regulations) and local building codes.
Multi-pole disconnection capability is required in the fixed installation.
🔒 Safety Features & Certifications
Built-in Safety:
- ✅ Temperature Cut-Out Protection – Automatically shuts down if overheating occurs; easily reset via front-access button
- ✅ Overheat Protection – Protects components, heating elements, and sauna woodwork from thermal damage
- ✅ Safety Thermostat – Secondary protection layer (spare part 9600 0914)
- ✅ Thermosafe™ Coating – Reduced surface temperature on external casing
- ✅ Auto-Shutoff Timer – Maximum 3-hour operation prevents unattended use
- ✅ IPX4 Splash Protection – Rated for sauna moisture environments
Certifications:
- ✅ CE Marked
- ✅ CB Certified (Certificate SE-107550)
- ✅ IPX4 Rated
- ✅ RoHS Compliant
Safety Warnings:
- Installation by qualified electrician mandatory
- Only one heater permitted per sauna cabin
- Never cover the heater – fire hazard
- Keep children away from the heater at all times
- Persons with health conditions should consult a doctor before sauna use
- Never pour undiluted fragrance oils directly onto stones – fire risk
🏠 Ideal Applications
| Application | Room Size | Capacity | Notes |
|---|---|---|---|
| 🏠 Compact Home Sauna | 2 – 3 m³ | 1-2 people | Perfect for small bathroom conversions or dedicated wellness corners |
| 🏠 Ensuite Sauna | 2 – 4 m³ | 1-2 people | Ideal for luxury bathroom integrations |
| 🏡 Garden Pod Sauna | 2 – 4 m³ | 1-2 people | Outdoor installations (add 25% to volume calculation) |
| 🛖 Compact Cabin Sauna | 2.5 – 4 m³ | 2-3 people | Space-efficient cabin heating |
| 💆 Wellness Room | 2 – 3.5 m³ | 1-2 people | Therapy rooms and small spa spaces |
Perfect Replacement For:
- Tylö Compact 2/4 (direct replacement model)
- Other compact 2-4 kW heaters requiring modernisation
🪨 Sauna Stones
- Stone Capacity: 7 kg
- Recommended Stone Size: 30 – 50 mm diameter
- Stones Included: No (sold separately)
- Recommended Type: Dolerite/Diabase (TylöHelo Sauna Stones recommended)
- Replacement Interval: Check annually or as frequently as sessions per week; replace damaged stones as needed
Stone Installation:
- Fill compartment around heating elements from bottom to top
- Stones should extend approximately 50 mm above the front top edge
- Place stones loosely – never press into position
- Ensure air can circulate freely between stones
- Never place stones on top of the side air chambers
⚠️ Warning: Do not use ordinary stones – they may damage the heater. Ceramic stones are prohibited and void the warranty.
🎛️ Control Options & Accessories
Built-in Control System:
- Type: Integrated mechanical controls
- Timer: 0-3 hours continuous operation with 9-hour delay pre-select function
- Thermostat: Adjustable for temperatures between 60-90°C
- Temperature Sensor: Capillary-type sensor, wall-mounted 400 mm below ceiling
How to Use:
- Turn thermostat dial to desired temperature (typically 60-90°C)
- For immediate start: Turn timer past 3h mark then back to desired run time (1, 2, or 3 hours)
- For delayed start: Turn timer to 9h mark then back to desired delay time
- Timer automatically stops at 0 position
Available Spare Parts:
| Part Number | Description |
|---|---|
| 9600 0900 | Grille |
| 9600 0902 | 2 × 2.2 kW Tubular Element |
| 9600 0904 | Timer Dial |
| 9600 0012 | Timer 9+3 6-Pole |
| 9600 0906 | Thermostat Dial |
| 9600 0908 | Thermostat |
| 9600 0914 | Safety Thermostat |
❓ Frequently Asked Questions
Q: What size room will this heater work for? A: The Sense Sport 2/4 operates at two power levels. At 2.2 kW, it suits rooms of 2-2.5 m³. At 4.5 kW, it heats rooms between 2-4 m³. For rooms with glass doors or uninsulated walls, add 1.2-2 m³ per square metre of these surfaces to your calculation.
Q: How long does it take to heat up? A: Typically 20-30 minutes to reach optimal temperature of 60-90°C, depending on room size, insulation quality, and ambient temperature.
Q: What electrical supply do I need? A: This depends on your power setting. The 2.2 kW setting requires 200-240V with a 10A circuit. The 4.5 kW setting can use either 400V 2-phase with 10A, or 230V single-phase with a 20A circuit. Professional installation by a qualified electrician is mandatory.
Q: Are sauna stones included? A: No, stones are sold separately. The heater requires 7 kg of dolerite/diabase sauna stones (30-50 mm diameter). We recommend TylöHelo branded stones for optimal performance and warranty compliance.
Q: What is the warranty? A: TylöHelo products carry a manufacturer warranty. Contact Parts4Tubs for specific warranty terms and conditions applicable to your purchase.
Q: Can I install this outdoors? A: The heater is designed for indoor sauna cabins. For outdoor pod or cabin saunas, ensure the sauna structure itself provides full weather protection. The exhaust vent must never lead directly outdoors.
Q: Is this a replacement for the Tylö Compact 2/4? A: Yes, the Sense Sport 2/4 is the direct replacement for the discontinued Tylö Compact 2/4, offering enhanced features including Split Output technology and improved efficiency.
Q: How often should I check the stones? A: Check the stone compartment at least once annually, or as many times per year as you use the heater per week. For example, using the sauna 3 times weekly means checking stones 3 times yearly.
📥 Downloads & Resources
📄 SENSE SPORT 2-4 Installation Guide – Complete installation instructions with wiring diagrams and clearance specifications
📄 SENSE SPORT 2-4 User Guide – Operating instructions, maintenance guidance, and troubleshooting
📄 CB Certificate SE-107550 – Safety certification documentation
📄 CB Test Report – Detailed test report documentation
🏆 Why Choose the Tylö Sense Sport 2/4
- ✅ Swedish Engineering Excellence – TylöHelo’s legacy of premium sauna manufacturing since 1950
- ✅ Energy Efficient Split Output – Up to 30% energy savings through intelligent power management
- ✅ Compact Yet Powerful – Maximum heating capability in a space-saving wall-mounted design
- ✅ Built-in Convenience – Integrated controls eliminate need for separate control panels
- ✅ Authentic Sauna Experience – 7 kg stone capacity for genuine löyly and traditional Finnish bathing
- ✅ Proven Reliability – CB certified with comprehensive safety features and quality components
🤝 Why Buy From Parts4Tubs
- ✅ UK-based company with local support
- ✅ Fast UK delivery
- ✅ Expert advice from sauna and hot tub specialists
- ✅ Competitive pricing
- ✅ Full warranty support
- ✅ Easy returns within 30 days
- ✅ Genuine TylöHelo authorised products
✨ Summary
The Tylö Sense Sport 2/4 delivers Swedish-engineered excellence for compact sauna spaces between 2-4 m³. Featuring innovative Split Output technology for up to 30% energy savings, dual power settings (2.2 kW / 4.5 kW), and a 7 kg stone capacity for authentic steam generation, this wall-mounted heater transforms intimate spaces into genuine Finnish sauna retreats. Complete with integrated timer and thermostat controls, Thermosafe™ surface protection, and comprehensive CB certification, the Sense Sport 2/4 offers premium performance in a space-efficient package. Backed by TylöHelo’s 70+ years of sauna heritage and Parts4Tubs’ expert UK support – order today for fast delivery.
