🎛️ Tylö External Switch Box 12V for Pure & Elite Control Panels

Convenient Remote Sauna Control from Any Location in Your Home or Facility

♨️ Product Overview

The Tylö External Switch Box 12V is an essential accessory for sauna owners who want the flexibility to control their sauna heater from a location separate to the main control panel. Manufactured by Tylö, the renowned Swedish sauna specialists with over 70 years of expertise, this compact switching unit delivers reliable remote on/off functionality with intelligent LED status indication.

Whether you’re installing a home sauna with the control panel in a utility area, or managing a commercial wellness facility where staff need convenient access points, this external switch provides the perfect solution. The integrated LED indicator keeps you informed of your sauna’s status at a glance, displaying whether the heater is running, programmed for delayed start, or if attention is needed.

Compatible with Tylö’s Pure, Elite, and CC series control panels, this switch seamlessly integrates into your existing sauna control system using low-voltage wiring for safe, flexible installation.

✨ Key Features

✅ Remote On/Off Control – Start and stop your sauna from any convenient location, separate from the main control panel

✅ Intelligent LED Status Indicator – Built-in LED clearly shows heater status: solid light when running, slow flash for delayed start programming, rapid flash for door alerts

✅ Universal Tylö Compatibility – Works with Pure, Elite, Elite Cloud, CC50, CC100, CC200, and CC300 control panels

✅ Safe 12V Low Voltage Operation – Uses low voltage wiring for safe installation at extended distances from the heater

✅ Flexible Positioning – Mount anywhere outside the sauna cabin at any convenient distance from the control panel

✅ Impulse or Constant Switching – Heater circuit automatically detects which switching mode is being used

✅ Door Contact Integration – Works with magnetic door contacts for enhanced safety and functionality

✅ Compact Design – Small footprint allows discreet installation in any location

✅ Swedish Engineering – Manufactured by Tylö with over 70 years of sauna expertise

🔧 Technical Specifications

Specification	Detail
Model	External Switch Box
Part Number	3090908047
Operating Voltage	12V DC (low voltage)
Switching Type	Impulse or constant (auto-detected)
LED Indicator	Yes – multi-function status display
Dimensions (L × W × H)	50 × 40 × 100 mm
Weight	0.05 kg
Mounting	External wall mounting
Connection	Low voltage wire to control panel
Manufacturer	Tylö (Sweden)

⚙️ Compatibility

This external switch is designed for use with the following Tylö control panels:

Control Panel	Compatibility	Notes
Tylö Elite Cloud	✅ Full Support	WiFi-enabled touchscreen control
Tylö Elite	✅ Full Support	Advanced touchscreen control
Tylö Pure	✅ Full Support	LED display control panel
Tylö CC50	✅ Full Support	Digital control panel
Tylö CC100	✅ Full Support	Digital control panel
Tylö CC200	✅ Full Support	Digital control panel
Tylö CC300	✅ Full Support	Digital control panel

⚠️ Important: A door contact must be installed for full functionality including delayed start features and calendar programming on Elite panels.

💡 LED Status Indicator Guide

The built-in LED provides clear visual feedback on your sauna’s operating status:

LED Behaviour	Meaning
Solid/Continuous Light	Heater is on and running
Slow Flash	Heater is programmed for delayed start
Rapid Flash	Door has been opened during delayed start, or door open for more than 5 minutes during operation
No Light	Heater is off and not programmed

This intelligent indication system allows you to check your sauna status at a glance without needing to access the main control panel.

🛠️ Installation Requirements

Electrical Connection:

• Low voltage (12V) wiring from control panel to switch location
• No high voltage electrical work required at the switch location
• Professional installation recommended

Mounting:

• Position anywhere outside the sauna cabin
• Wall-mounted installation
• Keep accessible for convenient operation

Additional Requirements:

• Compatible Tylö control panel (Pure, Elite, or CC series)
• Magnetic door contact (required for delayed start and calendar functions)
• Low voltage cable (appropriate length for installation distance)

⚠️ Note: The external switch can be positioned at any distance from the control panel. For installations exceeding approximately 23 metres (75 feet), consider potential voltage loss in the cable.

🎯 Ideal Applications

Application	Benefit
🏠 Home Saunas	Place switch near changing area while control panel stays in utility room
🏢 Commercial Spas	Staff control at reception desk while main panel is secured
🧖 Wellness Centres	Multiple access points for convenient operation
🏨 Hotel Saunas	Guest-accessible on/off control with protected main settings
🏋️ Gym Facilities	Staff can control sauna from fitness desk
🛖 Garden Saunas	Indoor switch when control panel is in outbuilding

❓ Frequently Asked Questions

Q: Can I use this switch to adjust temperature or timer settings? A: No, this is an on/off switch only. Temperature, timer, and other settings must be configured at the main control panel (Pure, Elite, or CC). The external switch simply starts or stops the sauna session using the pre-programmed settings.

Q: Do I need to install a door contact? A: A door contact is required for full functionality, particularly if you want to use the delayed start feature or calendar programming on Elite panels. The LED will indicate door-related alerts when a contact is installed.

Q: How far can the switch be installed from the control panel? A: The switch can be positioned at any convenient distance outside the sauna. For very long cable runs (over approximately 23 metres), consider potential voltage loss. Low voltage wiring makes extended installations safe and practical.

Q: Is this switch weatherproof for outdoor installation? A: This switch is designed for indoor installation in a dry location. For outdoor sauna buildings, install the switch inside a protected area such as a changing room or covered porch.

Q: What voltage is required? A: The switch operates on 12V DC low voltage, supplied from the control panel. No mains electrical connection is required at the switch location.

Q: Will this work with non-Tylö heaters? A: No, this external switch is specifically designed for Tylö control systems (Pure, Elite, and CC series). It will not function with other manufacturers’ control panels.

👍 Why Choose the Tylö External Switch Box

✅ Genuine Tylö Quality – Authentic Swedish-manufactured accessory with guaranteed compatibility

✅ Enhanced Convenience – Control your sauna from wherever suits your lifestyle or facility layout

✅ Clear Status Indication – Always know your sauna’s operating status at a glance

✅ Safe Low Voltage – 12V operation means safe, flexible installation without complex electrical work

✅ Universal Tylö Compatibility – Works across the Pure, Elite, and CC control panel ranges

✅ Professional Integration – Seamlessly connects to your existing Tylö control system

🤝 Why Buy from Parts4Tubs

✅ UK-Based Company – Local support from our Northamptonshire headquarters

✅ Genuine Tylö Parts – Authorised supplier of authentic Tylö accessories

✅ Expert Advice – Sauna specialists available to answer your technical questions

✅ Fast UK Delivery – Quick dispatch to get your project completed

✅ Competitive Pricing – Great value on genuine Tylö accessories

✅ Easy Returns – 30-day returns policy for peace of mind

✨ Summary

The Tylö External Switch Box 12V provides convenient remote on/off control for your sauna, allowing you to start and stop heating sessions from any location separate to the main control panel. With its intelligent LED status indicator, universal Tylö compatibility (Pure, Elite, and CC panels), and safe 12V low voltage operation, this compact Swedish-engineered accessory is the ideal addition for home saunas, commercial spas, and wellness facilities. Backed by Tylö’s renowned quality and Parts4Tubs expert UK support, order today for fast delivery.
