🎛️ Tylö CC50 Control Panel – Digital Sauna & Steam Room Controller

Swedish-engineered precision control for your sauna heater or steam generator – programmable, secure, and effortlessly reliable.

♨️ Product Overview

The Tylö CC50 Control Panel delivers intuitive digital control for sauna heaters and steam generators, combining Swedish engineering excellence with practical functionality. This versatile electronic control unit features a clear digital display showing real-time temperature and timer information, push-button operation, and advanced security features that make it ideal for both domestic and commercial sauna installations.

Manufactured by TylöHelo – the world’s leading sauna and steam company with over 70 years of expertise – the CC50 offers flexible programming options from quick 1-hour sessions to 24-hour continuous operation. The built-in code lock prevents unauthorised changes to settings, making it perfect for shared facilities, rental properties, or family homes where consistent, safe operation is essential.

With IP24-rated protection suitable for sauna environments and compatibility with a wide range of Tylö heaters and steam generators, the CC50 represents the ideal upgrade for anyone seeking reliable, feature-rich sauna control.

⭐ Key Features

✅ Digital Display – Clear LED readout shows both temperature and remaining bath time simultaneously, eliminating guesswork during your sauna session

✅ Flexible Programming – Select from 1, 3, 12, or 24-hour operation modes plus continuous running for commercial applications

✅ Delayed Start Timer – Programme your sauna up to 10 hours in advance so it’s perfectly heated when you arrive home or wake up

✅ Integrated Lighting Control – Built-in switch for sauna lighting that automatically activates with the heater or can be controlled independently

✅ Security Code Lock – Dual-level protection prevents unauthorised users from changing temperature settings or all settings entirely

✅ IP24 Protection Rating – Designed for the demanding sauna environment with protection against water splashes

✅ Universal Compatibility – Works directly with Tylö SE heaters or with Deluxe and older SK/SD/SDK models via relay box

✅ Steam Generator Support – Fully compatible with Tylö VA and VB steam generators for steam room applications

✅ Low Voltage Operation – Safe, low-voltage connection allows flexible installation positioning inside or outside the sauna

✅ Swedish Quality – Backed by TylöHelo’s 70+ years of wellness industry expertise and commitment to excellence

🔧 Technical Specifications

Specification	Value
Model	CC50
Part Number	3071114005
Display Type	Digital LED
Timer Range	0-24 hours
Preset Timer Options	0-10 hours delayed start
Programme Modes	1, 3, 12, 24 hours + continuous
Dimensions (L×W×H)	300 × 140 × 70 mm
Weight	0.5 kg
IP Rating	IP24
Security	Dual code lock function
Lighting Control	Integrated on/off switch
Installation Position	Inside sauna (max 1000mm above floor) or outside
Manufacturer	TylöHelo (Sweden)

📐 Compatibility Guide

The CC50 Control Panel is designed to work with a range of Tylö sauna heaters and steam generators. Compatibility depends on your heater model:

Direct Connection (No Additional Components):

Heater Series	Connection Type	Notes
Tylö SE Series	Direct wiring	Connects straight to heater terminal

With Relay Box RB30:

Heater Series	Connection Type	Notes
Tylö Deluxe 7 & 8	Via RB30 relay box	Relay box required (sold separately)
Tylö SK Series	Via RB30 relay box	For older Sense SK models
Tylö SD/SDK Series	Via RB30 relay box	Legacy heater models

Steam Generators:

Generator Series	Connection Type	Notes
Tylö VA Series	Direct/via relay	Check specific model requirements
Tylö VB Series	Direct/via relay	Check specific model requirements

💡 Tip: If upgrading from an older Tylö heater, the CC50 can typically be connected to provide modern digital control – contact Parts4Tubs for specific compatibility advice.

---

⚡ Installation Requirements

Mounting Positions:

Location	Maximum Height	Distance from Heater
Inside sauna	1000 mm above floor	Minimum 30 cm from heater
Outside sauna	Any height	Unlimited cable distance

Electrical Requirements:

Requirement	Specification
Connection Type	Low voltage control cable
Cable Type	Shielded cable (LiYCY 6-core) for relay box connections
Dedicated Circuit	Via connected heater
Installation	By qualified electrician

General Installation Notes:

• The control panel can be surface-mounted or recessed into the wall
• If recessed inside the sauna, insulation must be fitted behind the panel
• Control cable routing should avoid heat sources and sharp bends
• Clean, dry mounting surface required
• Wall bracket or double-sided adhesive mounting options

⚠️ IMPORTANT: All electrical installation must be carried out by a qualified electrician in accordance with BS 7671 (IET Wiring Regulations) and local building codes. The CC50 controls the heater’s electrical supply – improper installation can result in fire risk or electric shock.

---

🛡️ Safety Features & Certifications

Built-in Safety:

✅ Code lock prevents unauthorised temperature changes

✅ Separate code lock option to prevent any setting modifications

✅ Maximum timer limits prevent indefinite operation

✅ Low voltage control circuit for safer installation

✅ IP24-rated enclosure for splash protection

Certifications:

✅ CE Marked

✅ IP24 Rated for sauna environments

✅ Manufactured to Swedish quality standards

✅ Compliant with European safety directives

---

🎯 Ideal Applications

Application	Suitability	Notes
🏠 Home Sauna	✅ Excellent	Perfect for family use with security features
🛖 Garden Sauna	✅ Excellent	Weather-protected installation outside cabin
🪵 Barrel Sauna	✅ Excellent	Mount externally for easy access
🧖 Small Commercial Spa	✅ Excellent	Code lock ideal for shared facilities
🏨 Hotel/B&B	✅ Excellent	Prevents guest tampering with settings
🏋️ Gym/Fitness Centre	✅ Good	Consider CC100 for higher-capacity installations
♨️ Steam Room	✅ Excellent	Compatible with Tylö VA/VB generators

---

🎛️ Control Functions & Operation

Display Functions:

The CC50’s digital display provides clear indication of:

• Current temperature setting (°C)
• Remaining bath time (hours:minutes)
• Operating status
• Delayed start countdown

Operating Modes:

Mode	Duration	Best For
Quick Session	1 hour	Brief heat therapy or cool-down
Standard Session	3 hours	Typical home sauna use
Extended Session	12 hours	Day-long availability
Full Day	24 hours	Commercial/continuous access
Continuous	Unlimited	Professional installations with supervision

Programming the Delayed Start:

1. With the sauna switched off, press TIME to access hour setting
2. Use arrow buttons to set desired delay (0-10 hours)
3. Press TIME again to set minutes if required
4. Press ON to activate – the LED will blink until start time
5. Sauna will automatically heat at programmed time

Security Code Lock:

• Temperature Lock: Prevents changes to temperature setting only
• Full Lock: Prevents changes to all settings
• Easy activation and deactivation with button combinations

---

❓ Frequently Asked Questions

Q: What heaters is the CC50 compatible with? A: The CC50 works directly with Tylö SE series heaters. For Tylö Deluxe, SK, SD, and SDK models, you’ll need to add an RB30 relay box. It’s also compatible with Tylö VA and VB steam generators.

Q: Can I install the CC50 inside my sauna? A: Yes, provided the top of the panel is no more than 1000mm (1 metre) above the floor and at least 30cm from the heater. For easier access and a cleaner sauna interior, many users prefer external installation.

Q: Does the CC50 come with installation cables? A: Cabling requirements vary by installation. Contact Parts4Tubs for advice on the correct cable type and length for your specific setup.

Q: Can I upgrade my old Tylö heater with a CC50? A: Generally yes – older Tylö heaters can often be connected to a new CC50, though a relay box may be required. The CC50 cannot be used with heaters from other manufacturers.

Q: What’s the difference between CC50 and CC10? A: Both offer similar basic functionality, but the CC50 adds the delayed start feature (0-10 hours preset), additional programming modes (12 and 24 hours), and enhanced security options.

Q: Is the CC50 suitable for commercial use? A: Yes, particularly for smaller commercial installations. The code lock feature is especially valuable in shared facilities. For larger commercial saunas with multiple heaters, consider the CC100 or CC300 controllers.

Q: What warranty does the CC50 have? A: Tylö products typically carry a warranty on key components. Contact Parts4Tubs for current warranty terms applicable to your purchase.

📥 Downloads & Resources

📄 CC10/CC50 Operating Instructions Manual – Complete operating guide with all functions explained

🏆 Why Choose the Tylö CC50

✅ Swedish Engineering Heritage – Over 70 years of TylöHelo expertise in every product

✅ Proven Reliability – Millions of Tylö saunas sold worldwide with outstanding track record

✅ Practical Features – Delayed start, multiple programmes, and security lock for real-world convenience

✅ Universal Compatibility – Works with Tylö’s full range of heaters and steam generators

✅ IP24 Protection – Purpose-built for the demanding sauna environment

✅ Easy Operation – Intuitive push-button controls with clear digital display

✅ Future-Proof Investment – Can upgrade older Tylö heaters to modern digital control

🤝 Why Buy from Parts4Tubs

✅ UK-Based Company – Local support and understanding of UK electrical requirements

✅ Fast UK Delivery – In-stock items dispatched promptly

✅ Expert Advice – Knowledgeable team to help with compatibility and installation queries

✅ Competitive Pricing – Great value on genuine Tylö products

✅ Full Warranty Support – We stand behind every product we sell

✅ Easy Returns – 30-day returns policy for peace of mind

✨ Summary

The Tylö CC50 Control Panel brings Swedish precision engineering to your sauna or steam room installation. With its digital display, flexible programming from 1 to 24 hours (plus continuous mode), 10-hour delayed start capability, and dual-level security code lock, the CC50 provides everything needed for convenient, safe, and reliable sauna control. Compatible with Tylö’s extensive range of heaters and steam generators, and protected to IP24 standards, this control panel is the ideal choice for upgrading existing installations or completing new builds. Backed by Parts4Tubs’ expert UK support and fast delivery service.
