Norsup Heat pump Inverter aluminium 50 mm 10,3A 230VAC black type horizontal SG Silent-Pro 13

Name: Norsup Heat pump Inverter aluminium 50 mm 10,3A 230VAC black type horizontal SG Silent-Pro 13
SKU: 51728
Availability: InStock

Powerful | Ultra-Quiet | Smart-Integrated Heating Solution

Product Overview

The Norsup SG Silent-Pro 13 Inverter Heat Pump is engineered for larger residential pools, offering efficient and silent heating. Featuring advanced inverter technology, it adjusts heating capacity to match varying weather conditions, ensuring optimal performance year-round. The unit’s aluminium casing, titanium twisted heat exchanger, and SmartGrid compatibility make it a durable, eco-friendly, and future-ready choice for pool owners.

Key Features

Full Inverter Technology – Automatically adjusts heating capacity for maximum efficiency.
Ultra-Silent Operation – Noise level from 19 dB(A) with double-side airflow design.
SmartGrid Ready – Allows external signals to optimize power usage.
Wi-Fi Control – Integrated Wi-Fi module for remote monitoring and operation.
All-Season Performance – Operates effectively down to -15°C.
High COP – Coefficient of Performance up to 16, reducing energy costs.
Durable Construction – Titanium twisted heat exchanger resistant to salt and chlorine.
Eco-Friendly Refrigerant – Uses R32 gas with 3x lower GWP than R410A.
Soft Start Function – Prevents voltage peaks, protecting electrical systems.
Multiple Operating Modes – Power, Smart, and Silent modes for tailored energy use.
Automatic Functions – Includes auto heating, cooling, and defrost for ease of use.
Robust Aluminium Cabinet – Stylish black finish with horizontal design.
Full Colour Touch Screen – Intuitive and user-friendly interface.
Winter Cover Included – Protects the unit during off-season.
Reliable Warranty – 5 years on the heat pump, 10 years on compressor & heat exchanger.

Technical Specifications

Specification	Details
Type	Horizontal, Inverter Heat Pump
Control System	Full colour touch screen
Energy Label	A
Part Number	7036141
Heating Capacity A27/W27 (max.–min.)	2.4 ~ 13 kW
Power Input (max.–min.)	0.145 ~ 1.96 kW
Heating Capacity A15/W25 (max.–min.)	1.6 ~ 9.1 kW
Power Input (max.–min.)	0.238 ~ 1.89 kW
Heating Capacity A10/W25 (max.–min.)	1.21 ~ 6.96 kW
Power Input (max.–min.)	0.23 ~ 1.87 kW
Heating Capacity A5/W25 (max.–min.)	0.99 ~ 5.54 kW
Heating Capacity A0°C/W25 (max.–min.)	0.79 ~ 4.21 kW
Heating Capacity A-5°C/W25 (max.–min.)	0.76 ~ 4.10 kW
Power Input (max.–min.)	0.22 ~ 1.86 kW
Suitable Pool Volume*	40 ~ 70 m³
Rated Current	10.3 A
Minimum Fuse	25 A
COP at A27/W27	16.5 ~ 6.6
COP at A15/W25	6.7 ~ 4.8
COP at A10/W25	5.25 ~ 3.72
COP at A5/W25	4.5 ~ 2.98
COP at A0/W25	3.33 ~ 2.17
COP at A-5/W25	2.89 ~ 2.01
Power Supply	220–240V / 1Ph
Heat Exchanger	Twist-titanium tube in PVC
Compressor Brand	Mitsubishi
Refrigerant	R32
Fan Quantity	1
Fan Direction	Horizontal
Fan Speed	400 ~ 800 rpm
Power Input of Fan	40 W
Noise Level (1m)	37 ~ 47 dB(A)
Noise Level (10m)	19 ~ 28.5 dB(A)
Water Connection	50 mm
Nominal Flow Volume	4.1 m³/h
Wi-Fi Module	Included
Defrost Function	Automatic
Operating Modes	Power / Smart / Silent
Cabinet Material	Aluminium (black finish)
Warranty	5 years (heat pump), 10 years (compressor & heat exchanger)
Net Dimensions (LxWxH)	1000 × 430 × 622 mm

Recommended Usage

Ideal for Larger Pools – Suitable for pools with volumes between 40–70 m³.
All-Season Heating – Operates effectively even in colder climates down to -15°C.
Smart Power Management – Compatible with SmartGrid technology for optimized energy use.
Remote Control – Wi-Fi integration allows for convenient remote operation.
Durable and Eco-Friendly – Built with corrosion-resistant materials and eco-friendly refrigerant.

Benefits

Energy Savings – High COP ensures reduced electricity consumption.
Silent Operation – Low noise levels make it ideal for residential areas.
Smart Control – Adjust and monitor via Wi-Fi or touchscreen.
Long-Term Durability – Constructed with premium materials for extended lifespan.
Year-Round Comfort – Maintains desired pool temperature throughout the year.
Eco-Conscious Choice – Utilizes environmentally friendly refrigerant.

Why Choose the Norsup SG Silent-Pro 13?

High Efficiency – Advanced inverter technology provides optimal performance.
Quiet Operation – Designed for minimal noise disruption.
Smart Integration – Compatible with SmartGrid and Wi-Fi for enhanced control.
Robust Build – Durable construction ensures longevity.
Comprehensive Warranty – 5-year warranty on the heat pump, 10 years on compressor & heat exchanger.

Summary

The Norsup SG Silent-Pro 13 Inverter Heat Pump is a top-tier choice for pool owners seeking efficient, silent, and smart-integrated heating solutions. Its advanced features, durable construction, and eco-friendly design make it a reliable option for maintaining optimal pool temperatures year-round.
