💪 LX SWIM100 Swimming Pool Pump – 1.5 HP Self-Priming

High-performance circulation for larger swimming pools

🌊 Product Overview

The LX SWIM100 is a high-performance self-priming swimming pool pump delivering 1.5 HP of motor power for robust water circulation in larger pool systems. With a 1.1 kW power rating drawing 5.8A, this single-speed pump provides exceptional water turnover for pools demanding maximum filtration performance.

As the most powerful model in the LX SWIM series, the SWIM100 delivers triple the power of the entry-level SWIM025 whilst maintaining the same compact footprint. The stainless steel motor shaft and corrosion-resistant aluminium housing ensure years of reliable operation, even in demanding continuous-duty applications.

The self-priming design allows flexible installation above water level, whilst the standard 1.5″ (50mm) plumbing connections integrate seamlessly with existing pool filtration systems. Operating at 230V/50Hz, this pump is ideal for larger residential pools, small commercial installations, and systems requiring rapid water turnover.

✨ Key Features

✅ Self-Priming Design – Flexible installation above water level

✅ 1.5 HP Motor – Maximum power in the SWIM series

✅ 1.1 kW Power Rating – Strong, efficient performance

✅ 5.8A Current Draw – Designed for demanding applications

✅ Stainless Steel Shaft – Corrosion-resistant motor shaft

✅ Aluminium Housing – Durable, lightweight construction

✅ 1.5″ Plumbing – Standard 50mm connections

✅ Single Speed – Simple, reliable operation

✅ Compact Dimensions – 560mm × 275mm × 390mm

✅ 230V / 50Hz – UK standard electrical supply

⚙️ Technical Specifications

Specification	Value
Product Type	Self-Priming Pool Pump
Brand	LX
Model	SWIM100
SKU	PP-SWP15
Motor Power	1.5 HP
Power (kW)	1.1 kW
Speed Settings	Single Speed
Voltage	230 V
Frequency	50 Hz
Amperage	5.8 A
Plumbing Size	1.5″ (50 mm)
Length	560 mm
Width	275 mm
Height	390 mm
Motor Shaft	Stainless Steel
Housing Material	Aluminium

⚡ Electrical Requirements

Electrical Specification	Value
Supply Voltage	230 V
Frequency	50 Hz
Full Load Amps	5.8 A
Power Rating	1.1 kW
Phase	Single Phase

Component	Specification
Recommended MCB	10 A minimum
Recommended Cable	1.5 mm² minimum

⚠️ IMPORTANT ELECTRICAL SAFETY:

All electrical work must be carried out by a qualified electrician in accordance with UK wiring regulations (BS 7671). Outdoor pool pump installations require appropriate weatherproof enclosures and RCD protection (30mA). Ensure proper earthing and bonding of all electrical components.

🔗 Compatibility Guide

This Pump Specifications:

📍 Brand: LX 📍 Model: SWIM100 📍 Type: Self-Priming Pool Pump 📍 Motor Power: 1.5 HP / 1.1 kW 📍 Plumbing: 1.5″ (50mm) 📍 Voltage: 230V / 50Hz 📍 Current: 5.8A 📍 Dimensions: 560mm × 275mm × 390mm

Plumbing Connections:

Connection	Size
Inlet	1.5″ (50 mm)
Outlet	1.5″ (50 mm)

Suitable For:

• Large above-ground swimming pools
• Medium to large in-ground pools
• High-flow filtration systems
• Commercial water features
• Pools requiring rapid water turnover
• Small commercial pool installations

🔄 LX SWIM Series Comparison

Specification	SWIM025	SWIM035	SWIM050	SWIM100
SKU	PP-SWP50	PP-SWP75	PP-SWP10	PP-SWP15
Motor Power	0.5 HP	0.75 HP	1.0 HP	1.5 HP
Power (kW)	0.37 kW	0.55 kW	0.75 kW	1.1 kW
Amperage	1.9 A	2.7 A	3.8 A	5.8 A
Plumbing	1.5″	1.5″	1.5″	1.5″
Dimensions	560×275×390mm	560×275×390mm	560×275×390mm	560×275×390mm
Best For	Small pools	Medium pools	Med-large pools	Large pools

💡 Maximum Power: The SWIM100 delivers 3× the power of SWIM025 in the same compact footprint!

🛠️ Installation Requirements

Pump Dimensions:

Dimension	Measurement
Length	560 mm
Width	275 mm
Height	390 mm

Plumbing Connections:

Connection	Size
Inlet	1.5″ (50 mm)
Outlet	1.5″ (50 mm)

Installation Notes:

✅ Self-priming – can be installed above water level

⚠️ Prime pump before first use

⚠️ Ensure strainer basket is clean before operation

⚠️ Install on solid, level base

⚠️ Provide adequate ventilation around motor

⚠️ Protect from weather with suitable enclosure

⚠️ Ensure proper electrical bonding to earth

💡 Maximum suction lift – refer to manufacturer documentation

💡 Install isolation valves for easy maintenance

💡 Keep pump accessible for servicing

🔧 Maintenance Guide

Routine Maintenance:

Task	Frequency	Notes
Clean strainer basket	Weekly	Remove leaves and debris
Check for leaks	Weekly	Inspect unions and seals
Inspect pump lid o-ring	Monthly	Replace if worn or cracked
Check motor ventilation	Monthly	Keep vents clear
Inspect plumbing connections	Monthly	Tighten if needed
Check amperage	Annually	Should match 5.8A rating

Warning Signs – Service Required:

• Pump losing prime frequently
• Unusual noise (grinding, screeching)
• Water leaking from pump housing
• Motor overheating
• Reduced water flow
• Motor trips circuit breaker

Winterisation:

⚠️ Drain pump completely before freezing temperatures

⚠️ Remove and store drain plugs

⚠️ Protect from frost damage

🎯 Ideal Applications

Application	Suitability	Notes
🏊 Large above-ground pools	Excellent	Maximum power
🏊 Medium-large in-ground pools	Excellent	High flow rate
🏊 High-flow filtration	Excellent	Rapid water turnover
💧 Commercial water features	Good	Heavy-duty performance
💧 Small commercial pools	Good	Professional grade

❓ Frequently Asked Questions

Q: What size pool is this pump suitable for? A: The LX SWIM100 1.5 HP pump is the most powerful in the SWIM series, designed for larger residential pools and small commercial installations requiring high water turnover. Contact Parts4Tubs for sizing advice.

Q: Is this pump self-priming? A: Yes, this is a self-priming pump, meaning it can be installed above water level and will draw water up to the pump. Ensure the pump is primed before first use.

Q: What are the plumbing connection sizes? A: The pump has 1.5″ (50mm) inlet and outlet connections, compatible with standard pool plumbing.

Q: How much electricity does this pump use? A: The pump draws 5.8A at 230V, with a power rating of 1.1 kW. This is the highest power model in the SWIM series.

Q: How does this compare to other models in the SWIM series? A: The SWIM100 delivers 1.5 HP (1.1 kW) – three times the power of the SWIM025 (0.5 HP). All models share identical dimensions and plumbing, making upgrades straightforward.

Q: Can this pump be used outdoors? A: Yes, but it must be protected from weather with a suitable pump housing or enclosure. Electrical connections must be weatherproof.

Q: What maintenance does this pump require? A: Regular maintenance includes cleaning the strainer basket weekly, checking for leaks, and ensuring motor ventilation is clear. See the maintenance guide above.

Q: What warranty is included? A: Contact Parts4Tubs for warranty information and terms.

🏆 Why Choose the LX SWIM100 Pool Pump

✅ Maximum Power – 1.5 HP for demanding applications

✅ Self-Priming – Flexible installation options

✅ High Flow Rate – Rapid water turnover

✅ Durable Build – Stainless steel shaft, aluminium housing

✅ Same Footprint – Direct upgrade from smaller models

✅ Reliable LX Brand – Proven pump manufacturer

✅ Standard Connections – 1.5″ plumbing for easy installation

✅ Professional Grade – Suitable for commercial use

🤝 Why Buy From Parts4Tubs

✅ UK-based company with expert local support

✅ Fast UK delivery options available

✅ Knowledgeable advice from water equipment specialists

✅ Competitive pricing

✅ Full warranty support

✅ Replacement parts and accessories available

✅ Easy returns within 30 days

✨ Summary

The LX SWIM100 is the most powerful pump in the LX SWIM series, delivering 1.5 HP of self-priming pool pump performance for larger swimming pools and demanding applications. Featuring durable construction with stainless steel motor shaft and aluminium housing, this single-speed pump provides maximum flow rate for rapid water turnover. The 1.1 kW power rating draws 5.8A at 230V/50Hz, delivering three times the power of the entry-level SWIM025. Standard 1.5″ (50mm) plumbing connections ensure easy integration with existing filtration systems. Compact dimensions of 560mm × 275mm × 390mm match all other models in the series, allowing straightforward upgrades without installation changes. Ideal for large above-ground pools, medium to large in-ground pools, and small commercial installations requiring professional-grade performance.
