CIV100 Certikin Inverter Pool Pump (1kW) Description

Product Overview

The CIV100 Certikin Inverter Pool Pump (1kW) is a cutting-edge, energy-efficient pump designed to enhance swimming pool filtration systems for both residential and light-commercial applications. Powered by iSAVER+ inverter technology, the CIV100 offers unparalleled energy savings, quiet operation, and precise control over water flow, making it an ideal choice for pool owners seeking performance, cost-efficiency, and sustainability. With its robust construction, user-friendly touchscreen interface, and compatibility with most single-speed pumps, this pump delivers cleaner water, lower running costs, and a quieter pool environment, all backed by Certikin’s reputation for quality and reliability.

Key Features

• Inverter Technology: Utilizes iSAVER+ inverter technology for precise control over pump speed and run times, reducing energy consumption by up to 80% at low speeds.

• Energy Efficiency: Dynamically adjusts motor speed to save up to £419.62 annually for a 50m³ pool with a 1HP pump (based on UK electricity rates of £0.144 per kWh).

• Quiet Operation: Operates at below 60 dBA, significantly quieter than traditional single-speed pumps (up to 70 dBA), ensuring a peaceful poolside experience.

• User-Friendly Interface: Features a pioneering touchscreen frequency converter with real-time power consumption readings for intuitive control.

• Timer Functionality: Offers up to four customizable timers with individual speed settings for flexible scheduling of filtration and backwashing.

• Compatibility: Suitable for single-phase pumps up to 1HP (0.75kW), compatible with 95% of single-speed pool pumps for easy retrofitting or new installations.

• Durable Construction: Built with a UV-stabilized, fiberglass-filled pump body for corrosion resistance and durability, even in salt-chlorinated pools.

• Easy Maintenance: Includes a clear pump lid for quick basket inspection, simplifying routine maintenance.

• Simple Installation: Supplied with a 2.5m pump connection cable, 90cm power source cable, and 2” quick-connect unions (1.5” reducers included). Electrical installation requires a qualified professional.

Benefits

• Cost Savings: Reduces energy costs by up to 80%, with a payback period often less than 12 months.

• Enhanced Filtration: Precise flow control improves water circulation and filtration, ensuring cleaner and healthier pool water.

• Extended Equipment Lifespan: Lower speeds reduce wear, extending the life of the pump and pool components.

• Eco-Friendly: Lower energy use reduces your carbon footprint, making it an environmentally conscious choice.

• Quiet Pool Environment: Minimal noise levels create a more enjoyable swimming experience.

Technical Specifications

Specification	Details
Power Output	1kW (suitable for pumps up to 1HP/0.75kW)
Phase	Single-phase
Connection	2” quick-connect unions (1.5” reducers included)
Material	UV-stabilized, corrosion-resistant fiberglass-filled body
Noise Level	Below 60 dBA at typical operating speeds
Seal	316 high-grade mechanical seal with secondary seal for motor protection
Approvals	TUV approved, CE compliant

Installation Tips

• Professional Installation: Ensure electrical connections are handled by a certified electrician to comply with local regulations and ensure safety.

• Proper Placement: Install on a stable, level surface with adequate ventilation to prevent overheating. Avoid direct exposure to extreme weather.

• Pipe Alignment: Use the included 2” quick-connect unions (or 1.5” reducers) for a secure, leak-free connection. Align pipes to avoid stress on the pump.

• Initial Setup: Configure the touchscreen interface to set timers and speeds. Test at low speed to verify operation before full use.

• Priming the Pump: Ensure the pump is fully primed with water before operation to prevent dry running, which can damage the mechanical seal.

Maintenance Advice

• Regular Basket Cleaning: Check and clean the pump basket weekly to prevent debris buildup. The clear lid allows easy inspection.

• Inspect Seals: Check the mechanical seal periodically for wear or leaks, especially in salt-chlorinated pools, and replace if needed.

• Clean Impeller: Inspect the impeller every 6 months for blockages or wear, and clean gently to maintain performance.

• Monitor Performance: Use the touchscreen to track power consumption and ensure normal operation. Unusual readings may indicate maintenance needs.

• Winterizing: Drain the pump completely during off-season storage in colder climates to prevent freezing damage.

Comparison with Traditional Pumps

Feature	CIV100 Inverter Pump	Traditional Single-Speed Pump
Energy Efficiency	Up to 80% energy savings with variable speed	High energy consumption, fixed speed
Noise Level	Below 60 dBA, quiet operation	Up to 70 dBA, noticeably louder
Control	Touchscreen with timers and speed settings	No speed control, manual on/off
Lifespan	Extended due to reduced wear at lower speeds	Shorter due to constant high-speed operation
Cost Savings	Significant savings (e.g., £419.62/year)	Higher running costs
Environmental Impact	Eco-friendly with lower energy use	Higher carbon footprint

Why Choose the CIV100 Certikin Inverter Pool Pump?

The CIV100 combines Certikin’s trusted Aquaspeed pump design with advanced iSAVER+ inverter technology, offering unmatched performance, efficiency, and durability. Ideal for upgrading existing systems or new installations, it provides cost-effective, eco-friendly pool maintenance with reduced operational costs. Its intuitive touchscreen, customizable timers, robust construction, and broad compatibility make it a top choice for pool owners seeking reliability, savings, and a quieter pool environment.
