🌟 Balboa/Pentair Durajet Spa Pump – 2HP Dual Speed

Versatile two-speed operation combining Balboa motor reliability with Pentair wet end performance

♨️ Product Overview

The Balboa/Pentair Durajet 2.0 HP Two-Speed Pump is a reliable and flexible solution for spa and hot tub applications. It features a Balboa motor integrated with a Pentair wet end, offering two-speed operation for different spa functionalities – powerful jets on high speed and efficient filtration on low speed.

With rotatable wet ends for versatile plumbing configurations, this pump delivers effective performance with reduced running costs compared to single-speed alternatives. Operating at 230V/50Hz, the pump provides a low-speed current draw of just 1.9A at 1,400 RPM and a high-speed current draw of 9.0A at 2,800 RPM.

This pump is commonly used in Dimension One Spas, HotSpring, and Master Spas, making it an ideal replacement for owners of these popular spa brands seeking a reliable dual-speed pump solution.

✨ Key Features

✅ 2HP Motor Power – 1.5 kW output for effective jet propulsion and water circulation

✅ Dual Speed Operation – Two speeds for versatile spa functionality and energy savings

✅ Energy Efficient Low Speed – Just 1.9A draw on low speed for economical filtration

✅ Balboa Motor – Quality motor from a trusted spa industry manufacturer

✅ Pentair Wet End – Proven wet end engineering for reliable hydraulic performance

✅ 2-Inch Plumbing – Standard 2″ union connections for broad compatibility

✅ Rotatable Wet End – Flexible installation with adjustable wet end positioning

✅ Multiple Spa Brand Compatible – Commonly found in Dimension One, HotSpring, and Master Spas

📊 Technical Specifications

Specification	Value
Pump Type	Massage Pump (Jet) – Dual Speed
Brand	Balboa (Motor) / Pentair (Wet End)
Motor Power	2.0 HP
Power Output	1.5 kW
Speed Settings	Dual Speed (High/Low)
Voltage	230 V
Frequency	50 Hz
Amperage (High Speed)	9.0 A
Amperage (Low Speed)	1.9 A
Motor Speed (High)	2800 RPM
Motor Speed (Low)	1400 RPM
Plumbing Size	2 inch
Dimensions (L × W × H)	440 × 215 × 210 mm
Electrical Connection	4-core cable (not supplied)

⚡ Electrical Requirements

Electrical Specification	High Speed	Low Speed
Supply Voltage	230 V	230 V
Frequency	50 Hz	50 Hz
Full Load Amps	9.0 A	1.9 A
Motor Speed	2800 RPM	1400 RPM

General Requirement	Specification
Power Output	1.5 kW
Minimum Circuit Breaker	16 A (recommended)
Cable Required	4-core (not supplied)

⚠️ IMPORTANT ELECTRICAL SAFETY:

All electrical work must be carried out by a qualified electrician in accordance with UK wiring regulations (BS 7671). Hot tubs require RCD protection (30mA). Ensure proper earthing and bonding of all electrical components. Cable is not supplied with this pump – a suitable 4-core cable must be sourced separately for proper dual-speed operation.

🔗 Compatibility Guide

This Pump Specifications:

📍 Motor: Balboa 📍 Wet End: Pentair 📍 Plumbing Size: 2 inch unions 📍 Speed: Dual speed (High/Low) 📍 Wet End Position: Rotatable for flexible installation

Commonly Found In:

• Dimension One Spas
• HotSpring hot tubs
• Master Spas
• Other spa systems using Balboa/Pentair pump combinations

⚙️ Installation Requirements

Physical Dimensions:

Dimension	Measurement
Length	440 mm
Width	215 mm
Height	210 mm

Plumbing Connections:

Connection	Size
Unions	2 inch

Installation Notes:

⚠️ Pump must be installed below water level (flooded suction) to ensure proper priming

⚠️ Never run the pump dry – this causes seal damage

⚠️ Ensure proper electrical bonding to earth

⚠️ Cable not supplied – source appropriate 4-core cable separately for dual-speed operation

⚠️ Verify spa pack compatibility for 2-speed operation before installation

💡 The wet end can be rotated for flexible installation to accommodate your specific plumbing configuration

🛠️ Maintenance Guide

Routine Maintenance:

Task	Frequency	Notes
Check for leaks	Monthly	Inspect around seal plate and union connections
Inspect unions	Monthly	Tighten if necessary, check O-rings
Clean strainer/filter	As needed	Remove debris to maintain flow
Check amperage draw	Annually	High: 9.0A, Low: 1.9A
Inspect motor vents	Quarterly	Keep clear of debris
Check mounting bolts	Quarterly	Tighten if vibration has loosened
Test both speeds	Monthly	Ensure proper speed switching

Warning Signs – Consider Replacement If:

• Unusual noise (grinding, screeching, or humming)
• Water leaking from the seal plate area
• Motor trips the circuit breaker repeatedly
• Noticeably reduced water flow to jets
• Motor overheating or hot to touch
• One speed fails to operate
• Visible corrosion or damage to motor housing

🎯 Ideal Applications

Application	Suitability	Notes
♨️ Hot Tub Jet Pump	Yes	High speed for jets, low speed for filtration
♨️ Dimension One Spas	Yes	Commonly found in D1 models
♨️ HotSpring Spas	Yes	Compatible replacement option
♨️ Master Spas	Yes	Suitable for Master Spa systems
♨️ Energy-Conscious Spas	Yes	Low speed reduces running costs
🛁 Whirlpool Bath	Yes	Suitable for whirlpool applications

❓ Frequently Asked Questions

Q: What horsepower is this pump? A: This is a 2HP (1.5 kW) dual-speed massage pump.

Q: What is the benefit of a dual-speed pump? A: Dual-speed operation allows powerful jet massage on high speed (9.0A) whilst using energy-efficient low speed (1.9A) for filtration and heating cycles, significantly reducing running costs.

Q: What voltage does this pump require? A: 230V / 50Hz. All electrical installation must be carried out by a qualified electrician in accordance with BS 7671.

Q: Does the pump come with a cable? A: No, this pump requires a 4-core cable which is not supplied. You will need to source an appropriate cable separately for proper dual-speed operation.

Q: What are the dimensions of this pump? A: The pump measures 440mm (length) × 215mm (width) × 210mm (height).

Q: What size are the plumbing connections? A: The pump uses 2-inch union connections.

Q: Can the wet end be rotated? A: Yes, the wet end can be rotated for flexible installation to suit your plumbing configuration.

Q: What spa brands use this pump? A: This pump is commonly found in Dimension One Spas, HotSpring, and Master Spas.

Q: What amperage does this pump draw? A: High speed: 9.0A at 2800 RPM. Low speed: 1.9A at 1400 RPM.

Q: How do I know if my pump needs replacing? A: Common signs include unusual noises, water leaking from the seal, reduced jet pressure, the motor tripping the breaker, or failure of one speed to operate.

🏆 Why Choose the Balboa/Pentair Durajet Dual Speed

✅ Trusted Brands – Combines Balboa motor reliability with Pentair wet end engineering

✅ Energy Savings – Low speed at 1.9A vs 9.0A high speed reduces running costs

✅ Versatile Operation – Two speeds for both powerful jets and efficient filtration

✅ Flexible Installation – Rotatable wet end accommodates various plumbing configurations

✅ Multi-Brand Compatible – Fits Dimension One, HotSpring, Master Spas and more

✅ Standard Connections – 2-inch unions for broad compatibility

🤝 Why Buy From Parts4Tubs

✅ UK-based company with expert local support

✅ Fast UK delivery options available

✅ Knowledgeable advice from spa industry specialists

✅ Competitive pricing on quality spa pumps

✅ Full warranty support

✅ Replacement seals and accessories available

✅ Easy returns within 30 days

💫 Summary

The Balboa/Pentair Durajet 2HP Dual Speed Spa Pump combines a reliable Balboa motor with a proven Pentair wet end for versatile two-speed operation in spa and hot tub systems. Delivering 1.5 kW of power with 9.0A on high speed (2800 RPM) and just 1.9A on low speed (1400 RPM), this pump offers both powerful jet performance and energy-efficient filtration. With compact dimensions (440 × 215 × 210mm), 2-inch union connections, and a rotatable wet end, it provides flexible installation options. Commonly found in Dimension One Spas, HotSpring, and Master Spas. Note: 4-core cable not supplied.

The hot tub industry doesnt make it easy for you when you are trying to match up the size of the unions (the part that screws your pipe work onto the pumps) Below you can see the physical sizes of the collars, and how they relate to the actual union size you need. So a measurement of 2.5", edge to edge on the collar of the pump is actually a 1.5" union - confusing - absolutely! If you are not sure, give me a shout!

How do I Replace a Hot Tub Pump?

Here's a general step-by-step guide on how to replace a hot tub pump. Keep in mind that the specific steps may vary depending on your hot tub's make and model, so it's essential to consult your hot tub's manual for model-specific instructions. If you're not comfortable with this procedure, it's a good idea to seek professional assistance.

Materials You'll Need:

• Replacement pump
• Pipe wrench
• Adjustable wrench
• Screwdriver
• Pipe sealant (thread tape or plumber's putty)
• PVC primer and cement (if you have PVC plumbing)
• Teflon tape (for threaded connections)

Procedure:

1. Turn Off the Power: Before you begin, ensure the hot tub's power supply is turned off at the circuit breaker or disconnect switch. Safety should always be a priority when working with electrical components.
2. Drain the Hot Tub: If your hot tub is not already empty, you'll need to drain it. Follow your hot tub's manual or manufacturer's instructions for proper draining. (You might not need to do this if you can lock the pump off with the gate valves)
3. Locate the Pump: Identify the location of the existing pump in your hot tub. It's usually located near the equipment area or in a designated pump compartment.
4. Disconnect the Electrical Wiring: Carefully disconnect the electrical wiring from the old pump. This typically involves removing the electrical conduit cover, unscrewing wire nuts, and disconnecting the wires from the terminals. Be sure to note the wire connections or take a picture for reference when connecting the new pump.
5. Disconnect the Plumbing: Depending on your hot tub's plumbing setup, you'll need to disconnect the plumbing connections to the pump. Use a pipe wrench or adjustable wrench to loosen and remove the fittings. Be prepared for some water spillage when disconnecting the plumbing.
6. Remove the Old Pump: Once the electrical and plumbing connections are detached, carefully remove the old pump from its mounting position. Some pumps may be secured with mounting brackets or bolts.
7. Prepare the New Pump: If the new pump is not pre-assembled, you may need to attach fittings, unions, or adapters to match your hot tub's plumbing. Ensure that you use the appropriate sealant or Teflon tape on threaded connections to prevent leaks.
8. Mount the New Pump: Position the new pump in the same location as the old one and secure it in place using the mounting brackets or bolts.
9. Reconnect Plumbing: Reconnect the plumbing to the new pump, ensuring that all connections are tight and secure. If your hot tub uses PVC plumbing, use PVC primer and cement to bond the connections properly.
10. Reconnect Electrical Wiring: Reconnect the electrical wiring to the new pump, following the notes or pictures you took earlier. Make sure all wires are properly connected and secure.
11. Turn On the Power: Restore power to the hot tub by switching on the circuit breaker or reconnecting the disconnect switch.
12. Test the Pump: Turn on the hot tub's pump to ensure that it's working correctly. Check for any signs of leaks or irregularities in the plumbing connections.
13. Refill the Hot Tub: Once you've confirmed that the new pump is functioning properly, refill the hot tub with water.
14. Check for Leaks: Inspect the plumbing connections for any leaks. If you find any, turn off the pump, drain the tub again, and reseal the connections as needed.
15. Monitor: Keep an eye on the pump and plumbing for the next few days to ensure everything is functioning correctly and that there are no further issues.

Remember that this is a general guideline, and the specific steps may vary based on your hot tub's design. If you're unsure or uncomfortable with any aspect of this process, please do get in touch, happy to help.

How do I know what size hot tub pump I have?

Determining the size of your hot tub pump is an important step when it comes to maintenance or replacement. To find out the size of your hot tub pump, follow these steps:

1. Check the Manual: The easiest way to determine the size of your hot tub pump is to consult the owner's manual or user documentation that came with your hot tub. The manual typically contains detailed information about the specifications and components of your hot tub, including the pump.
2. Look at the Pump Housing: If you don't have access to the manual or it doesn't provide the information you need, inspect the pump itself. Most hot tub pumps have a label or plate on the pump housing that displays essential details, including the pump's model number, manufacturer, and specifications. You can then send that to me or Google it.
3. Measure the Pump: If the label is missing or damaged, you can measure the pump's dimensions. Measure the diameter of the pump's wet end (the part where the water flows) and the length of the wet end. These measurements can help identify the size and capacity of the pump.
4. Consult the Manufacturer: If you can't find the information on the pump or in the manual, contact the hot tub manufacturer or a reputable dealer. Provide them with your hot tub's model and serial number, and they should be able to identify the correct pump size for your specific hot tub.
5. Online Research: You can also search online using the pump's model number or hot tub's make and model. Many manufacturers provide detailed information about their products on their websites, and you may find specifications for your pump model.

Once you have determined the size and specifications of your hot tub pump, you can proceed with maintenance, repairs, or replacement if necessary. Keep in mind that replacing a hot tub pump with the same size and capacity as the original is crucial to ensure proper water circulation and filtration in your hot tub. If you're unsure about any aspect of this process, get in touch, always happy to help.
